Name: 8-Channel Temperature Data Logger - 5" Color Display, -200℃ to 1372℃, Supports KJETNSRB Thermocouples
Brand: morelian
SKU: SHTDE20199EUPY
Price: 697.68 SAR
Availability: InStock

Highlights

Temperature Recorder -- Supports 8 channels, high accuracy, -200℃~1372℃ wide temperature measuring range, 1s record interval. Built in 8G large memory, supports U disk file export.
5-inch Color Screen & Comfortable Buttons -- 5-inch TFT color screen, 6 digits display, with 854*480 resolution, easy to read, clear at a glance. With comfortable buttons for easy setting and operation.
Display Form & Multiple Interface Display: Supports 4/ 8/ 16/ 32 multi-interface real-time value display; supports curve and bar charts real-time display of measured data.
Quick Response & Stable Performance: Adopts advanced 32-bit microprocessor, features quick response, supports multi-channel data collecting, recording, display and alarm.
Support Thermocouples: K-type, J-type, E-type, T-type, N-type, S-type, R-type and B-type thermocouple. Each channel supports individual parameters settings and arbitrary naming.

Key Attributes

SKU ID	SHTDE20199EUPY
Dimensions (Length x Width x Height)	43cm x 33cm x 20.5cm
weight	5817.9g
Stock Location	China
Country of Origin	China
Brand	Morelian

Shipment Information

Weight per item	5817.9 g
Dimensions per item (LWH)	43 x 33 x 20.5 cm
Carton weight	5817.9 g
Carton dimensions (LWH)	43 x 33 x 20.5 cm
Pieces per carton	1
Stock location	China

The machine uses 32-bit microprocessor to collect data quickly, and with 5-inch TFT screen display for easy reading. It supports K-type, J-type, E-type, T-type, N-type, S-type, R-type and B-type thermocouple. With multiple display modes and simple operation, it's suitable for production, R&D needs. It can be widely used in lighting appliances, power tools, household appliances, motors, electric heating appliances, medical, petroleum, chemical, metallurgical, electricity and more fields! Note: 1. Please read the user manual carefully before use. 2. Size and color may be slightly different due to manual measurement and different light conditions. Thanks for understanding. Specifications: Voltage & Plug: 220V, EU/ 110V, US (Optional) Color: Grey & Blue Material: Metal ' ABS Screen: 5" TFT Screen, 854*480 Resolution Number of Channel: 8 Support Thermocouple: KJETNSRB Measurement Range: 60mV Accuracy: 0.05%FS Temperature Display Resolution: 0.1℃ Cold End Compensation Accuracy: ±0.5℃ Temperature Measuring Range: -200~1372℃ (the equipped K-type thermocouple) Measuring Speed: 1s/channel (slow), 0.5s/channel (medium) Display: Numerical, Curve Chart, Bar Chart Calibration: Isolated Correction Factor of Each Channel Alarm: Yes Record Interval: 1s Memory: 8GB Communication Interface: USB Working Temperature: 0~40℃ Storage Temperature: -10~50℃ Humidity: ＜80% RH Item Size: 300 * 260 * 100mm / 11.81 * 10.24 * 3.94in Item Weight: 3014g / 6.65lbs Package Size: 43 * 33 * 20.5cm / 16.93 * 12.99 * 8.07in Package Weight: 4066g / 8.96lbs Package List: 1 * Multi-channel Temperature Recorder 1 * Power Cord 1 * K-type Thermocouple (2m) 1 * User Manual (English)

Overview

Product Description

8-Channel Temperature Data Logger - 5" Color Display, -200℃ to 1372℃, Supports KJETNSRB Thermocouples
